Installing the Ball Mount Adapter

Your device includes a one-inch ball mount that is compatible with third-party mounting solutions.

  1. Remove the four screws Callout number one securing the mount socket Callout number two to the magnetic mount.

    Mount adapter with callouts
  2. Remove the mount socket.
  3. Secure the one-inch ball mount Callout number three to the magnetic mount using the screws removed in step 1.

    Ball mount installation with callouts
