Replacing the Depth-Adjustment Collar
- Remove the shaft (Removing the Shaft).
- Slide the depth adjustment collar up and off the shaft.
-
Install the new depth adjustment collar on the shaft, making sure it is in the
correct orientation.
The depth adjustment collar is keyed to fit the shaft in a certain orientation. If you meet any resistance, rotate the shaft adjustment collar until it slides onto the shaft easily.
- Slide the shaft down towards the propeller drive motor to keep it out of the way as you reinstall the shaft.
- Reinstall the shaft (Reinstalling the Shaft).
